Specifications
| Color | |
|---|---|
| Product Dimensions (L × W × H in) | 18.8 x 15.7 x 18.1 |
| Brand | Hurricane™ |
| Product Dimensions (L × W × H mm) | 477.5 x 398.8 x 459.7 |
| Shipping Box Dimensions | 23.00 × 20.00 × 17.00 in |
| Weight | 23.000 lbs |
| Bundle | Monitor Only |
| Monitor Type | Standard Mounting |
| Certifications | FM |
| Monitor Supply Size (Imp) | 4" |
| Monitor Supply Size (Met) | 100 mm |
| Monitor Supply Type | ANSI 150/DN100 PN16 |
| Monitor Supply Style | 4.5" (115 mm) Riser Flange |
| Monitor Supply Swivel | Rigid |
| Monitor Horizontal Control | Lock Lever |
| Monitor Horizontal Range | 360° |
| Monitor Vertical Control | 6" Handwheel |
| Monitor Vertical Range | -90° – 90° |
| Monitor Control | Handwheel & Lock Lever |
| Monitor Supply Inlets | Single |
| Monitor Outlet Size (Imp) | 2.5" |
| Monitor Outlet Size (Met) | 65 mm |
| Monitor Outlet Type | NH Male |
| Monitor Outlet Style | Male Threads |
| Monitor Outlet Swivel | Rigid |
| Max Flow Rate (GPM) | 1250 GPM |
| Max Flow Rate (LPM) | 4500 LPM |
| Swing Radius (in) | 9.7 |
| Swing Radius (mm) | 246.4 |
