Protector Tiller 1250 GPM (4500 LPM) Monitor, Standard – 3″ (75 mm) ANSI 150/DN80 PN16 Rigid Flange Inlet, 2.5″ (65 mm) NHM Rigid Outlet, Red

Call for Price: 219-462-6161

image_pdf
SKU: Z1211A Category:

Rugged and Reliable Industrial Firefighting Monitor

The Protector™ industrial fixed station monitor delivers exceptional performance with a flow capacity of up to 1250 GPM (4750 LPM). Engineered for durability and efficiency, the Protector offers full 360° rotation, low friction loss, and optional integrated features to enhance your firefighting operations.

Key Features:

  • High-Capacity Flow: Capable of flowing up to 1250 GPM (4750 LPM), the Protector provides powerful water delivery for industrial firefighting applications
  • Full 360° Rotation: The monitor’s full rotational ability allows precise water stream direction, ensuring coverage of all critical areas without repositioning the unit
  • Low Friction Loss: The patented waterway design with integral stream-shaping vanes minimizes friction loss, maximizing flow efficiency for longer reach and higher performance
  • Optional Integrated Shutoff Valve: Eliminate the need for additional valves with a built-in shutoff valve that offers intuitive control – horizontal for “OFF” and vertical for “ON” positions
  • Automatic Drain Valve: Protects against corrosion and freezing by ensuring complete drainage of the monitor after use – the integrated drain valve is conveniently located above the valve seat
  • Durable Construction: Built with hard coat anodized aluminum and powder-coated inside and out for superior resistance to harsh environments – stainless steel hardware ensures long-lasting reliability
  • Easy Maintenance: The Protector requires no grease or specialized maintenance – swiveling elements and seals, including the valve seat, can be replaced in minutes using standard tools
  • Flexible Mounting Options: Directly bolt the Protector to common pipe flanges – the outlet is available with 2.5″ (65 mm) male threads to accommodate various nozzle configurations
  • Ergonomic Control: The lever-action rotational lock securely holds the monitor in position, while the tiller bar provides intuitive manual operation for precise stream adjustments
  • High-Pressure Tolerance: Designed to withstand pressures of up to 250 PSI (17 bar), making it suitable for demanding industrial applications
  • Warranty and Identification: Each unit includes a laser-engraved serial number and is backed by a 5-year warranty for added peace of mind

All Prices in USD

Specifications

Weight 35.200 lbs
Oscillation

Remote Control

N

Color

Brand

Protector™

Bundle

Monitor Only

Monitor Type

Standard Mounting

Monitor Supply Size (Imp)

3"

Monitor Supply Size (Met)

75 mm

Monitor Supply Type

ANSI 150/DN80 PN16

Monitor Supply Style

Flange

Monitor Supply Swivel

Rigid

Monitor Horizontal Control

Tiller Bar

Monitor Horizontal Range

360°

Monitor Vertical Control

Tiller Bar

Monitor Vertical Range

-70° – 80°

Monitor Control

Tiller Bar

Monitor Supply Inlets

Single

Monitor Outlet Size (Imp)

2.5"

Monitor Outlet Size (Met)

65 mm

Monitor Outlet Type

NH Male

Monitor Outlet Style

Male Threads

Monitor Outlet Swivel

Rigid

Max Flow Rate (GPM)

1250 GPM

Max Flow Rate (LPM)

4500 LPM

Documents

Technical Specifications and Drawings

Service Procedures

Instructions For Installation, Safe Operation and Maintenance
