Specifications
| Color | |
|---|---|
| Product Dimensions (L × W × H in) | 22.8 x 12.1 x 16.5 |
| Brand | Hurricane™ |
| Product Dimensions (L × W × H mm) | 579.1 x 307.3 x 419.1 |
| Shipping Box Dimensions | 18.00 × 18.00 × 18.00 in |
| Weight | 18.200 lbs |
| Bundle | Monitor Only |
| Monitor Type | Standard Mounting |
| Certifications | FM |
| Monitor Supply Size (Imp) | 3" |
| Monitor Supply Size (Met) | 75 mm |
| Monitor Supply Type | NPT Female |
| Monitor Supply Style | Female Threads |
| Monitor Supply Swivel | Rigid |
| Monitor Horizontal Control | Tiller Bar |
| Monitor Horizontal Range | 360° |
| Monitor Vertical Control | 6" Handwheel |
| Monitor Vertical Range | -90° – 90° |
| Monitor Control | Tiller Bar & Handwheel |
| Monitor Supply Inlets | Single |
| Monitor Outlet Size (Imp) | 2.5" |
| Monitor Outlet Size (Met) | 65 mm |
| Monitor Outlet Type | NH Male |
| Monitor Outlet Style | Male Threads |
| Monitor Outlet Swivel | Rigid |
| Max Flow Rate (GPM) | 1250 GPM |
| Max Flow Rate (LPM) | 4500 LPM |
| Swing Radius (in) | 12.3 |
| Swing Radius (mm) | 312.4 |
